Hooke'sLaw&Multi-SpringSystems

Q: What does the slope of a Force vs Displacement graph represent?

The slope of the F vs Δx graph directly equals the spring constant k (stiffness) in N/m. The triangular area beneath the line represents the work done to stretch the spring, which equals the stored elastic potential energy Ue = ½k(Δx)².

Q: How does a spring scale measure mass in different gravitational fields?

At static equilibrium, the upward restoring force balances downward gravity: kΔx = mg, meaning mass is computed as m = (kΔx)/g. On the Moon where g is 1/6th of Earth, the same mass causes 1/6th as much stretch.

Q: Why does the oscillation period depend on mass but not on gravity?

The natural period of a spring-mass oscillator is T = 2π√(m/k). While gravity shifts the static equilibrium position downward (x_eq = mg/k), the restoring force gradient (dF/dx = -k) is purely elastic and independent of g.

Investigate how elastic springs stretch and oscillate under load. Configure springs in single, series, or parallel setups, measure displacement with a virtual ruler, weigh mystery masses, and plot linear force-displacement curves.

Launch Interactive Lab Read the theory

Hooke's Law & Multi-Spring Systems interactive Physics simulation illustration

Runge-Kutta RK4 Spring-Mass SimulatorSeries & Parallel Multi-Springs • Force-Displacement Slope • Mystery Mass Weighing

Interactive Experiment Guide

Use this studio like a real-time physics workbench

Start with fundamental scientific principles, launch the simulation, and verify mathematical predictions against real-time outcomes.

DisciplinePhysics

Simulation ModeInteractive Numeric Engine

Governing ModelRunge-Kutta RK4 Spring-Mass Simulator

DeploymentIn-Browser WebAssembly / GPU

Scientific Foundation

What is hooke's law & multi-spring systems?

Hooke's Law states that the restoring force exerted by an elastic spring is directly proportional to its displacement from equilibrium: Fs = -kΔx. For multi-spring systems, springs in parallel add stiffness (keff = k1 + k2), whereas springs in series add compliance (1/keff = 1/k1 + 1/k2). Under harmonic oscillation, the natural period is T = 2π√(m/keff), with total mechanical energy continually interchanging between elastic potential energy (Ue = ½k(Δx)²) and kinetic energy (Ek = ½mv²).

Interactive Simulation Flow

Experiment Execution & Governing Equations

Launch the simulation workspace, adjust parameters in real time, and observe the immediate response in the telemetry and graphical indicator loops.

Hooke's Law & Natural Oscillation PeriodF_s = -k_{\text{eff}} \Delta x \quad \text{and} \quad T = 2\pi\sqrt{\frac{m}{k_{\text{eff}}}}
